Product details

GENERAL Track luminaire for general illumination. Simple, compact form.

LIGHTING MANAGEMENT The choice of appropriate control gear enables integration into lighting management systems.

HOUSING/ OPTICS The satinised PMMA diffuser is shaped in such a way as to provide maximum surface for light emission and completely hide the extruded aluminium housing. Lateral PC caps in anthracite colour.

FEATURES Easy tool-free mounting and maintenance.

ADDITIONAL Other light colour temperatures available upon request.

Technical data

Track lighting in all directions
CE
CLASS 1
IP20
220-240V
50-60Hz
LED
* Please select the row to enable viewing and downloading of additional material.
Order code Description A/B/H[mm] WEIGHT [kg] FLUX [lm]* IP UGR Total Power [W] CCT [K] CRI Led Service Life
3513211XY LUCIA /T 700 / 840 670/68/125 1.30 1792 IP20 <22 14.0 4000 >80 60000h L80B10 /SDCM3
3513311XY LUCIA /T 1000 / 840 970/68/125 1.70 2688 IP20 <22 21.0 4000 >80 60000h L80B10 /SDCM3
3513411XY LUCIA /T 1300 / 840 1270/68/125 2.30 3584 IP20 <22 29.0 4000 >80 60000h L80B10 /SDCM3
3513511XY LUCIA /T 1600 / 840 1570/68/125 2.70 4480 IP20 <22 36.0 4000 >80 60000h L80B10 /SDCM3
* Luminaire luminous flux and connected electrical load - initial tolerance of ±10 % (at ambient temperature of 25° C).
