Product details
GENERAL High efficiency suspension luminaire for direct high quality illumination of office spaces.
OPTICS Opal diffuser provides a uniform diffusing light and a uniformly illuminated surface, without visible light sources.
LIGHTING MANAGEMENT The choice of appropriate control gear enables integration into lighting management systems.
HOUSING Luminaire of extruded aluminium. Finish: anodisation in natural aluminium colour or with epoxy polyester powder coating. Fine structured texture. Other colours available upon request.
FEATURES Option to form a long linear line adjusted to the space, in order to gain optimal light uniformity and aesthetic consistency of the interior.
EQUIPMENT Supplied with suspension kit.
ADDITIONAL To be ordered separately: EM module, enabling operation in the case of a power failure and other light colour temperatures.
Technical data
| Order code | Description | A/B/H[mm] | WEIGHT [kg] | FLUX [lm]* | IP | UGR | Total Power [W] | CCT [K] | CRI | Led Service Life |
|---|---|---|---|---|---|---|---|---|---|---|
| 2844311XY | PRIMA M DO /S 900 /840 HE | 862/83/100 | 2.50 | 1241 | IP40 | <22 | 11.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 2844341XY | PRIMA M DO /S 900 /840 HO | 862/83/100 | 2.50 | 2211 | IP40 | <25 | 20.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 2844421XY | PRIMA M DO /S 1200 /840 HE | 1148/83/100 | 3.20 | 1655 | IP40 | <22 | 14.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 2844441XY | PRIMA M DO /S 1200 /840 HO | 1148/83/100 | 3.20 | 2948 | IP40 | <25 | 27.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 2844521XY | PRIMA M DO /S 1500 /840 HE | 1434/83/100 | 4.00 | 2068 | IP40 | <22 | 18.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 2844541XY | PRIMA M DO /S 1500 /840 HO | 1434/83/100 | 4.00 | 3685 | IP40 | <25 | 33.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
