PRIMA S WW

Product details

GENERAL High efficiency surface mounted luminaire for direct high quality illumination of office spaces.

OPTICS Wall washing component is based on reflectors with complex surfaces micro facet technology. The reflectors ensure high uniformity in lighting distribution on plane with characteristic elongation in vertical direction. Precise cut off eliminating glare in adjacent areas.

LIGHTING MANAGEMENT The choice of appropriate control gear enables integration into lighting management systems, including dynamic white function.

HOUSING Luminaire of extruded aluminium. Finish: anodisation in natural aluminium colour or with epoxy polyester powder coating. Fine structured texture. Other colours available upon request.

FEATURES Possibility to form a long linear shape adjusted to the space, in order to gain optimal light uniformity and aesthetic consistency of the interior.

ADDITIONAL Dynamic White and other light colour temperatures available upon request.

Technical data

Wall washer ceiling
White finestructured paint
Gray finestructured paint
Black finestructured paint
CE
Zapaljivost F
CLASS 1
IP20
220-240V
50-60Hz
LED
* Please select the row to enable viewing and downloading of additional material.
Order code Description A/B/H[mm] WEIGHT [kg] FLUX [lm]* IP Total Power [W] CCT [K] CRI Led Service Life
2320111XY PRIMA S WW 900 /840 846/60/136 2.80 2081 IP20 19.0 4000 >80 50000h L80B10 /SCDM3
2320121XY PRIMA S WW 1200 /840 1126/60/136 3.60 2774 IP20 26.0 4000 >80 50000h L80B10 /SCDM3
2320131XY PRIMA S WW 1500 /840 1406/60/136 4.30 3468 IP20 32.0 4000 >80 50000h L80B10 /SCDM3
2320141XY PRIMA S WW 2400 /840 2248/60/136 7.00 5549 IP20 51.0 4000 >80 50000h L80B10 /SCDM3
* Luminaire luminous flux and connected electrical load - initial tolerance of ±10 % (at ambient temperature of 25° C).
