Product details

GENERALHigh energy and optical efficiency of recessed downlighters for direct illumination of office spaces, communication and reception areas. Strictly controlled glare and clean design makes this fitting an attractive architectural detail.

OPTICS Micro downlight reflector with complex surfaces geometry of micro facets allows precise shaping of light beam. Angles of direct light beam and light reflected from reflector are almost perfectly aligned, providing sharp cut off for full visual comfort.

LIGHTING MANAGEMENT The choice of appropriate control gear enables integration into lighting management systems.

HOUSING Housing is made of metal steel sheet. Finish: epoxy polyester powder coating. Fine structured texture. Other colours available upon request.

FEATURES Minimal height of the luminaire enables installation in recessed ceilings with limited mounting space.

APPLICATION Applicable to all modular lay-in ceilings.

ADDITIONAL Dynamic White and other light colour temperatures available on request.

Technical data

Recessed ceiling
White finestructured paint
Gray finestructured paint
Black finestructured paint
CE
Zapaljivost F
SELV
IP20
220-240V
50-60Hz
LED
* Please select the row to enable viewing and downloading of additional material.
Order code Description A/B/H[mm] WEIGHT [kg] FLUX [lm]* IP UGR Total Power [W] CCT [K] CRI Led Service Life
1520111XY ASTERISK 600 /840 595/595/20 4.30 3500 75° IP20 <13 23.0 4000 >80 60000h L80B10 /SDCM3
1520121XY ASTERISK 1200 /840 1195/295/20 4.30 3500 75° IP20 <16 23.0 4000 >80 60000h L80B10 /SDCM3
* Luminaire luminous flux and connected electrical load - initial tolerance of ±10 % (at ambient temperature of 25° C).
