MEGA CENT
Product details
GENERAL Recessed, fixed luminaire for general illumination.
LIGHTING MANAGEMENT The choice of appropriate control gear enables integration into lighting management systems.
HOUSING Die cast aluminium housing, with epoxy polyester powder coating.
APPLICATION Applicable to all types of suspended ceilings that can be cut through.
ADDITIONAL Other light colour temperatures available upon request.
Technical data
| Order code | Description | Ø/H[mm] | Ø/h[mm] | WEIGHT [kg] | FLUX [lm]* |
|
IP | UGR | Total Power [W] | CCT [K] | CRI | Led Service Life |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1575112XY | MEGA CENT 1700 63dg /840 | 170/160 | 160/220 | 0.20 | 1765 | 63° | IP20 | <19 | 13.0 | 4000 | >85 | 50000h L90B10 /SDCM3 |
| 1575116XY | MEGA CENT 3000 63dg /840 | 170/160 | 160/220 | 0.20 | 3045 | 63° | IP20 | <19 | 22.0 | 4000 | >80 | 50000h L90B10 /SDCM3 |
| 1575126XY | MEGA CENT 2000 35dg /940 | 170/120 | 160/180 | 0.20 | 1910 | 35° | IP20 | <16 | 20.0 | 4000 | >90 | 50000h L70/SDCM3 |
| 1575128XY | MEGA CENT 3000 35dg /940 | 170/120 | 160/180 | 0.20 | 2780 | 35° | IP20 | <19 | 29.0 | 4000 | >80 | 50000h L70/SDCM3 |
