NEO SPOT TB INT
Product details
GENERAL Surface mounted luminaire for direct illumination.
HOUSING Housing of aluminium sheet, with epoxy polyester powder coating. Fine structured texture.
ADDITIONAL Other light colour temperatures available upon request.
Technical data
| Order code | Description | Ø/H[mm] | WEIGHT [kg] | FLUX [lm]* | IP | UGR | Total Power [W] | CCT [K] | CRI | Led Service Life |
|---|---|---|---|---|---|---|---|---|---|---|
| 2240112XY | NEO SPOT TB INT 190-800 /830 | 130/190 | 1.00 | 706 | IP20 | <16 | 9.0 | 3000 | >80 | 50000h L70B50 /SDCM 3 |
| 2240117XY | NEO SPOT TB INT 190-2000 /840 | 130/190 | 1.00 | 1766 | IP20 | <19 | 18.0 | 4000 | >80 | 50000h L70B50 /SDCM3 |
| 2240122XY | NEO SPOT TB INT 450-800 /830 | 130/450 | 2.50 | 706 | IP20 | <16 | 9.0 | 3000 | >80 | 50000h L70B50 /SDCM3 |
| 2240127XY | NEO SPOT TB INT 450-2000 /840 | 130/450 | 2.50 | 1766 | IP20 | <19 | 18.0 | 4000 | >80 | 50000h L70B50 /SDCM3 |
| 2240132XY | NEO SPOT TB INT 900-800 /830 | 130/900 | 3.50 | 706 | IP20 | <16 | 9.0 | 3000 | >80 | 50000h L70B50 /SDCM3 |
| 2240137XY | NEO SPOT TB INT 900-2000 /840 | 130/900 | 3.50 | 1766 | IP20 | <19 | 18.0 | 4000 | >80 | 50000h L70B50 /SDCM3 |
