Product details

GENERAL High efficiency surface mounted luminaire for direct high-quality illumination of office spaces. Full visual comfort ensured with the latest optical and electrical components.

OPTICS Matt ‘dark light’ aluminium louver. Anodised highly diffusing silver plated aluminium, shaped in such a way as to provide efficient illumination with glare limitation.

LIGHTING MANAGEMENT The choice of appropriate control gear enables integration into lighting management systems.

HOUSING This luminaire is made of a 0.6mm thick steel sheet, with a special reflective white epoxy polyester powder coating.

ADDITIONAL This luminaire can be optionally equipped with an EM module, enabling operation in the case of a power failure. Other light colour temperatures available upon request.

Technical data

Ceiling mounted
White highly reflective paint
Zapaljivost F
* Please select the row to enable viewing and downloading of additional material.
Order code Description A/B/H[mm] WEIGHT [kg] FLUX [lm]* IP UGR Total Power [W] CCT [K] CRI Led Service Life
2011121XY ORIEN DLM 2 600 /840 HO 600/466/60 4.50 4979 IP20 <16 36.0 4000 >80 60000h L80B10 /SDCM3
2011122XY ORIEN DLM 2 600 /840 HE 600/466/60 4.50 3480 IP20 <16 24.0 4000 >80 60000h L80B10 /SDCM3
2011141XY ORIEN DLM 2 1200 /840 HO 1190/125/75 4.50 4979 IP20 <19 36.0 4000 >80 60000h L80B10 /SDCM3
2011142XY ORIEN DLM 2 1200 /840 HE 1190/125/75 4.50 3480 IP20 <19 24.0 4000 >80 60000h L80B10 /SDCM3
* Luminaire luminous flux and connected electrical load - initial tolerance of ±10 % (at ambient temperature of 25° C).
