Product details

HOUSING/ OPTICS Surface mounted extruded aluminium profile with curved opal diffuser to hold the LED module. Finish: anodisation in natural aluminium colour.

FEATURES Possibility to form long linear forms adjusted to the space, in order to obtain optimal light uniformity and aesthetic completeness of the interior.

ADDITIONAL Upon request: flexible LED light strip IP 20 or IP 65, controllable driver, other light colour temperatures.

Technical data

Ceiling mounted
Anodised aluminium
Zapaljivost F
* Please select the row to enable viewing and downloading of additional material.
Order code Description A/B/H[mm] WEIGHT [kg] FLUX [lm]* IP Total Power [W] CCT [K] CRI Led Service Life
2331421XY LED LINE 15 1200 /840 1140/28/16 0.60 2100 IP42 18.0 4000 >80 60000h L80B10 /SDCM3
2331521XY LED LINE 15 1500 /840 1420/28/16 0.80 2625 IP42 22.0 4000 >80 60000h L80B10 /SDCM3
2331621XY LED LINE 15 1800 /840 1700/28/16 1.00 3150 IP42 26.0 4000 >80 60000h L80B10 /SDCM3
* Luminaire luminous flux and connected electrical load - initial tolerance of ±10 % (at ambient temperature of 25° C).
