Product details
GENERAL Circular suspension luminaire for direct illumination of general puprose spaces.
OPTICS Highly transparent micro prismatic diffuser provides glare limitation (UGR< 19) and a uniform diffusing light. The opal foil provides a uniformly illuminated surface, without visible light sources.
LIGHTING MANAGEMENT The choice of appropriate control gear enables integration into lighting management systems.
HOUSING Housing of aluminium, with epoxy polyester powder coating of fine structured texture. The interior of the housing is highly reflective white coating, regardless the outer finish, for maintaining high efficiency of the luminaire.
EQUIPMENT Supplied with suspension kit.
ADDITIONAL Dynamic White and other light colour temperatures available upon request.
Technical data
| Order code | Description | Ø/H[mm] | WEIGHT [kg] | FLUX [lm]* | IP | UGR | Total Power [W] | CCT [K] | CRI | Led Service Life |
|---|---|---|---|---|---|---|---|---|---|---|
| 2740141XY | LUNA CDP /S 400 /840 | 400/110 | 4.00 | 2373 | IP40 | <22 | 20.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 2740221XY | LUNA CDP /S 600 /840 HE | 600/110 | 5.40 | 3165 | IP40 | <19 | 25.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 2740241XY | LUNA CDP /S 600 /840 HO | 600/110 | 5.40 | 4698 | IP40 | <19 | 38.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
