LUNA DO
Product details
GENERAL Circular recessed luminaire for direct illumination of general use spaces.
OPTICS Opal PC diffuser provides a uniform, soft light. Also available with CDP optics.
LIGHTING MANAGEMENT The choice of appropriate control gear enables integration into lighting management systems.
HOUSING Housing made of aluminium, with epoxy polyester powder coating. Fine structured texture. The interior of the housing is highly reflective white coating, regardless the outer finish, for maintaining high efficiency of the luminaire.
APPLICATION Applicable to suspended monolith plasterboard ceilings.
EQUIPMENT Supplied with mounting kit.
ADDITIONAL Dynamic White and other light colour temperatures available upon request.
Technical data
| Order code | Description | Ø/H[mm] | Ø/h[mm] | WEIGHT [kg] | FLUX [lm]* | IP | UGR | Total Power [W] | CCT [K] | CRI | Led Service Life |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1537141XY | LUNA DO 400 /840 | 400/110 | 400/150 | 4.00 | 1732 | IP40 | <22 | 17.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 1537221XY | LUNA DO 600 /840 HE | 600/110 | 600/150 | 5.40 | 2732 | IP40 | <22 | 25.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 1537241XY | LUNA DO 600 /840 HO | 600/110 | 600/150 | 5.40 | 4055 | IP40 | <22 | 38.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 1537321XY | LUNA DO 900 /840 HE | 900/110 | 900/150 | 10.70 | 7026 | IP40 | <22 | 63.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 1537341XY | LUNA DO 900 /840 HO | 900/110 | 900/150 | 12.00 | 10143 | IP40 | <22 | 94.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 1537421XY | LUNA DO 1200 /840 HE | 1200/110 | 1200/150 | 20.00 | 11711 | IP40 | <22 | 105.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
| 1537441XY | LUNA DO 1200 /840 HO | 1200/110 | 1200/150 | 18.00 | 16906 | IP40 | <22 | 157.0 | 4000 | >80 | 54000h L80B10 /SDCM 3 |
