Product details

GENERAL Recessed, fixed luminaire for general illumination.

LIGHTING MANAGEMENT The choice of appropriate control gear enables integration into lighting management systems.

HOUSING Die cast aluminium housing, with epoxy polyester powder coating.

APPLICATION Applicable to all types of suspended ceilings that can be cut through.

ADDITIONAL Other light colour temperatures available upon request.

Technical data

Recessed ceiling
White finestructured paint
CE
Zapaljivost F
SELV
IP20
220-240V
50-60Hz
LED
* Please select the row to enable viewing and downloading of additional material.
Order code Description Ø/H[mm] Ø/h[mm] WEIGHT [kg] FLUX [lm]* IP Total Power [W] CCT [K] CRI Led Service Life
1574212XY CENT 350 32dg /840 86/120 76/150 0.10 350 32° IP20 4.3 4000 >80 15000h L70 / SCDM6
1574214XY CENT 900 50dg /840 86/120 76/150 0.10 900 50° IP20 8.4 4000 >90 50000h L80B20 /SCDM3
1574216XY CENT 1200 48dg /840 86/120 76/150 0.10 1175 48° IP20 12.0 4000 >90 50000h L90B10 /SDCM3
* Luminaire luminous flux and connected electrical load - initial tolerance of ±10 % (at ambient temperature of 25° C).
